API Standard Nose Float Shoe Cementing Float Equipment with 150°C and 204°C Seals for Oilfield Drilling

150°C Seal Float Shoe

204°C Seal Cementing Float Equipment

Nose Float Casing Float Shoe

Menşe yeri:

Jiangsu, Çin

Marka adı:

SWS

Bize Ulaşın

Bir teklif isteği

API Standard Nose Float Shoe Cementing Float Equipment with 150°C and 204°C Seals for Oilfield Drilling

Ürün Detayları

Boyut:

50*30*30

Ağırlık:

10 kg

Çekirdek bileşenler:

Valf

Valf tipi:

Tek valf ve çift valf

İşleme türü:

Dövme

Spesifikasyon:

2-3/8 ~ 20 "

İplik türü:

BTC\LTC\ Özel Konu\AB\NU

Çelik sınıfı:

N80\L80\P110

OD delikli:

6 ", 7 5/8", 10 5/8 ", 14 3/8"

Taşınma Kimliği:

4 3/4 ", 6 1/4", 8 5/8 ", 12 3/8"

Min delik:

2 ", 2 3/8"

İplik türü:

5 1/2 "LCSG, 7" LCSG, 9 5/8 "LCSG, 13 3/8" LCSG

Basınç derecesi:

70MPA

Sıcaklık derecesi:

204°C

Valf boyutu:

70mm ve 90mm

ilgili ürünler

API Standard 114.3mm Float Shoe and Float Collar with 150°C and 204°C Seals for Oilfield Drilling

En İyi Fiyatı Alın

API Standard Nose Float Shoe Cementing Float Equipment with 150°C and 204°C Seals for Oilfield Drilling

En İyi Fiyatı Alın

API 5CT 7-5/8" L80 BTC/LTC Eccentric Multiple Flank Jets Aluminum Alloy Float Shoe for Cementing Tool

En İyi Fiyatı Alın

Customizable API 5CT High Pressure Double Plug Cementing Head with 35MPa Working Pressure and 1 Year Warranty

En İyi Fiyatı Alın

Bize Ulaşın

86-519-83553967

Leo@service-js.com

86-519-83553967

Şimdi İletişime Geçin

Ürün Açıklaması

API Standard Nose Float Shoe Cementing Tools

Product Specifications

Name	Size(in)	Bore O.D.(in)	Bore I.D.(in)	Min Bore Parameter(in)	Thread Type	lb(in2)
Float Collar	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
Float Shoe	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626

Product Features

Float equipment serves as the backbone of casing equipment used during primary cementing operations. Float equipment guides the casing to total depth and prevents contaminated mud from entering the casing. It also provides a landing point for casing wiper plugs, reinforces the lower end of the casing string, and ensures great accuracy of cement slurry displacement.

Key Specifications:

Hi Flow valves to reduce fluid erosion and minimize pressure drop
Available in two sizes: 70mm and 90mm
PDC drillable composite plastic materials for valve components
Standard seal rated to 150°C with optional 204°C seal
Valve body molded with fiber phenolic, 70MPa and 204°C seal
Spring purchased from Canada Victory Spring Company (phosphor bronze C510 material)
High restoring force and drillable design
Plunger seal top molded with HNBR, 70MPa and 204°C seal

Frequently Asked Questions

When can I get the price?

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard your inquiry as priority.

Could I have prices of your products?

Welcome. Please feel free to send us an email here. You will get our reply in 24 hours.

Can I get a lower price if I order large quantities?

Yes, cheaper prices are available for larger quantity orders.

Do you inspect the finished products?

Yes, each step of production and finished products will be inspected by our QC department before shipping.

What about the lead time for the mass production?

Honestly, it depends on the order quantity and the season you place the order.
